LinkPower™ LPS740P-T1, All-in-One Box
Unmanaged Outdoor Gigabit PoE Switch, Powered by 802.3bt
The LinkPower™ LPS740P-T1P is a high-performance, unmanaged 5-port gigabit outdoor PoE switch, engineered to deliver both power and data connectivity in demanding environments. Designed for seamless Power over Ethernet (PoE) distribution, it features one PoE++ (802.3bt) RJ45 uplink port, capable of receiving power and data, along with four PoE+ (802.3af/at) output ports, providing reliable connectivity for wireless access points (APs), IP cameras, VoIP phones, and IoT devices.
Encased in a rugged IP66/IP68-rated weatherproof enclosure, the LPS740P-T1P is built to withstand extreme outdoor conditions, ensuring durability and long-term reliability. With plug-and-play installation, this cost-effective switch simplifies network expansion for hotels, campuses, industrial sites, parks, and security monitoring applications, offering stable PoE connectivity over distances up to 200 meters.
Whether deployed in commercial, industrial, or remote outdoor environments, the LPS740P-T1P delivers the power, performance, and protection needed to maintain a robust and efficient PoE network.
- IP66 if top cover closed by latch or IP68 if top cover closed by screws
- Support non-blocking wire-speed forwarding for smoother transmission
- IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control
- 5*10/100/1000Base-T RJ45 ports, the uplink port is a power receiving port. Convenient and flexible networking to meet the network power supply and transmission within 200 meters
- IEEE 802.3af /at PoE standard automatically identifies PoE devices for power without damaging non-PoE devices
- 4*10/100/1000Base-T RJ45 ports support PoE power to meet the PoE power supply requirements of security scenarios
- High-power receiving port (60W) relay power, 8 cores are used at the same time
- CCC,CE, FCC, RoHS
- Plug and play, no configuration, easy to use and maintain
- Low power consumption, No fan, galvanized steel shell, excellent heat dissipation to ensure stable operation
- Operating Temperature:-22°F to +158°F (-30°C to +70°C)
Download
LPS740P-T1P Datasheet
PFCK0001-3 Power & Fiber Connector Kit
ECK0001-4 Ethernet Connector Kit
WMK0001 Wall Mounting Kit
APCK0001 AC Power Cable Kit
